Metal Fiber Laser Cutting Machine

Name: Metal Fiber Laser Cutting Machine
Brand: NUMAC HITECH
Price: 1650000.0 INR
Availability: InStock

Price 1650000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

Metal Fiber Laser Cutting Machine Specification

Product Type
Metal Fiber Laser Cutting Machine

General Use
Cutting and processing sheet metals

Material
Metal Sheets (Mild Steel, Stainless Steel, Aluminum, Brass, etc.)

Type
CNC Fiber Laser Cutting Machine

Capacity
Depends on configuration; up to 25-40mm thickness

Weight (kg)
Approx. 3200-4500kg depending on model

Computerized
Yes

Automatic
Yes

PLC Control
Available

Bar Feeder
Not Included

Power Source
Electric (Fiber Laser)

Power Consumption
Depends on Laser Source (Typically 1000W - 4000W or higher)

Rigidity
High Structural Strength

Voltage
380V / 50Hz (Can vary by configuration)

Motor
Inovance Servo Motor

Table Size
Customizable (Standard: 1500x3000mm, 1500x4000mm, etc.)

Spindle Speed
Not Applicable (No spindle, Laser cutting)

Axial Choice
X, Y, Z Axis movement

Dimension (L*W*H)
Custom as per model (Approx. 4500x2200x1700 mm)

Feature
Advanced Laser Technology, Precision Drive, System Integration

Color
White body with black and yellow accents

Cutting Control
Precision intelligent digital control

Supported File Formats
DXF, PLT, AI, LXD, etc.

Chiller Unit
S&A Industrial Chiller (Thermal Management)

System Integration
Advanced integrated platform for precision and reliability

Machine Structure
Heavy-duty welded bed for vibration resistance

Control Interface
Touch Screen HMI

Safety Feature
Integrated exhaust and optional enclosure available

Motion System
Servo-driven precision linear guideways

Laser Head
Raytools Cutting Head with Controller

Cooling System
Water cooling by high-efficiency industrial chiller

Laser Source
Raycus (High-Power Core)

Software Compatibility
Compatible with mainstream CAD/CAM software

Metal Fiber Laser Cutting Machine About

Highlighted as a celebrated solution in metal fabrication, the NH-530E Metal Fiber Laser Cutting Machine features the premier Raycus high-power core and the classic Raytools laser head. This machine includes an advanced integrated platform, affordable operation outlay, and jump-on precision with servo-driven linear guideways. Its heavy-duty welded bed maximizes vibration resistance, while Raycus' acclaimed fiber laser delivers swift, accurate cuts for a variety of metals. Benefit from an intelligent touch screen interface, customizable table sizes, and compatibility with most mainstream cutting software-making your operations truly effortless and reliable.

Versatile Applications for Every Industry

The Metal Fiber Laser Cutting Machine stands out for its flexible application across industries such as automotive, aerospace, and custom metalwork. Used primarily for the precision cutting and processing of sheet metals-like mild steel, stainless steel, aluminum, and brass-it offers unrivaled utility in both standardized production and bespoke fabrication. Whether you require intricate patterns or robust structural parts, this premier tool adapts to your general and specific needs with remarkable accuracy and efficiency.

Sample Policy, Certifications & Delivery Assurance

We provide a transparent sample policy tailored to your project needs, with minimal expenditure or outlay. The machine is supplied with comprehensive certifications, ensuring compliance with global industrial standards. Packaging is robust to ensure safe transit, and delivery time typically ranges from 15-30 days depending on model customization. Our dedicated service guarantees that each machine reaches you with full documentation and support, minimizing downtime and maximizing your investment.

Model	NH-530E
Working area	1500mm*3000mm	Reposition accuracy	0.02mm/1000mm
Laser type	Fiber laser generator	Graphic format supported	CAD. DXF (etc.)
Laser power	1.5 KW/3KW Raycus CE version	Working environment	Temp:0-40, humidity y: 80%, No condensation
Transmission system	Gantry double-drive structure	Total power	(Around) 20KW
Lubrication system	Full-automatic	Machine size	455022802100mm
Maximum speed	80m/min	Gross weight	3500kg
Maximum accelerated speed	1.0G	Position accuracy	0.03mm/1000mm
Machine body	Tube welded Gantry milling Destressing De-firing	Machine table bearing	1000kg

FAQ's of Metal Fiber Laser Cutting Machine:

Q: How does the NH-530E Metal Fiber Laser Cutting Machine ensure precision during operation?

A: The NH-530E achieves exceptional precision through its servo-driven linear guideways, heavy-duty welded bed and full-automatic lubrication system. Coupled with a reposition accuracy of up to 0.02mm/1000mm, it is designed for consistently accurate metal sheet processing.

Q: What materials and thicknesses can this machine cut?

A: The machine supports cutting of various metal sheets such as mild steel, stainless steel, aluminum, and brass. Depending on the configuration and selected laser power (up to 3KW), it can handle thicknesses typically ranging from 25mm to 40mm.

Q: What is the process for ordering and receiving a sample cut?

A: Customers can request a sample cut according to their design specifications. Once details are provided, our team promptly processes the sample, packages it securely, and arranges delivery while ensuring minimal expenditure for the client.

Q: Where can I install this laser cutting machine, and what are its electrical requirements?

A: This machine is suitable for installation in industrial environments with controlled temperature (0-40C) and humidity (80%). It operates on 380V / 50Hz power supply, with the total power depending on the specific configuration (around 20KW for the standard model).

Q: How does the cooling and safety system enhance operational reliability?

A: The S&A industrial chiller manages efficient cooling, preventing thermal overload during extended cutting sessions. Integrated exhaust and optional enclosure enhance both operator safety and environmental protection, maintaining stable machine performance.

Q: What benefits can users expect from the control interface and software compatibility?

A: The intuitive touch screen HMI and support for mainstream file formats (DXF, PLT, AI, LXD) guarantee smooth workflow integration. Compatibility with CAD/CAM software further simplifies the process, allowing streamlined transition from design to final cut.
